VUV/UV Noth-反射式滤光片 - Teledyne Acton Optics

China Distributor

北京波威科技有限公司

概述

波长	%反射率	1.0''零件编号	1.5''零件编号	2.0''零件编号
360 nm	≥ 90%	M360-3045-1D	M360-3045-1.5D	M360-3045-2D
352 nm	≥ 90%	M352-3045-1D	M352-3045-1.5D	M352-3045-2D
340 nm	≥ 90%	M340-3045-1D	M340-3045-1.5D	M340-3045-2D
320 nm	≥ 90%	M320-3045-1D	M320-3045-1.5D	M320-3045-2D
300 nm	≥ 90%	M300-3045-1D	M300-3045-1.5D	M300-3045-2D
280 nm	≥ 90%	M280-3045-1D	M280-3045-1.5D	M280-3045-2D
266 nm	≥ 90%	M266-3045-1D	M266-3045-1.5D	M266-3045-2D
260 nm	≥ 90%	M260-3045-1D	M260-3045-1.5D	M260-3045-2D
254 nm	≥ 90%	M254-3045-1D	M254-3045-1.5D	M254-3045-2D
248 nm	≥ 90%	M248-3045-1D	M248-3045-1.5D	M248-3045-2D
240 nm	≥ 90%	M240-3045-1D	M240-3045-1.5D	M240-3045-2D
220 nm	≥ 90%	M220-3045-1D	M220-3045-1.5D	M220-3045-2D
212 nm	≥ 90%	M212-3045-1D	M212-3045-1.5D	M212-3045-2D
208 nm	≥ 90%	M208-3045-1D	M208-3045-1.5D	M208-3045-2D
200 nm	≥ 90%	M200-3045-1D	M200-3045-1.5D	M200-3045-2D
193 nm	≥ 82%	M193-3045-1D	M193-3045-1.5D	M193-3045-2D
185 nm	≥ 82%	M185-3045-1D	M185-3045-1.5D	M185-3045-2D
172 nm	≥ 82%	M172-3045-1D	M172-3045-1.5D	M172-3045-2D
157 nm	≥ 82%	M157-3045-1D	M157-3045-1.5D	M157-3045-2D
146 nm	≥ 45%	M146-3045-1D	M146-3045-1.5D	M146-3045-2D
126 nm	≥ 40%	M126-3045-1D	M126-3045-1.5D	M126-3045-2D
